TDA7379 stereo amplifier - 2x 38 W at 4 ohms, AD828 preamp, 12-18 V
TDA7379 stereo amplifier - 2x 38 W at 4 ohms, AD828 preamp, 12-18 V
This goes with it
Pay in 30 days
Pay in 30 days
Description
Product overview
- Ready-to-use stereo amplifier with preamp stage for audio signals
- Power output of 2*38 W into 4-ohm speakers
- Amplifier stage with the AD828 IC as an operational amplifier
- Operating voltage of 12 to 18 V DC
- Easy connection via RCA inputs (Cinch) and speaker terminals
- Fully assembled with populated circuit board
Product description
This stereo amplifier combines an amplifier stage with the AD828 operational amplifier and the TDA7379 power amplifier IC for two channels. The module accepts line-level signals through RCA inputs and outputs them to commonly available 4-ohm speakers. The integrated preamp electronics process the signals before they drive the speakers.
The supply voltage is between 12 and 18 V DC, making operation with laboratory power supplies or automotive 12-V power supplies convenient. With 4-ohm speakers, each channel delivers 38 W. A higher speaker impedance noticeably reduces the available power; very low impedances below 4 ohms are not permitted and will damage the power amplifier.
Possible applications include multimedia uses such as home cinema accessories, small PA systems, amplified speakers, and DIY amplifiers in enclosure projects. In all cases, the power supply must meet the requirements when the current under load reaches two or three amperes.
A regulated DC power source (12 to 18 V) is required; unregulated power supplies are not sufficient. The circuit board requires a heatsink or a low-speed fan to prevent excessive heat during continuous operation. The power leads from the power source should be sufficiently thick to prevent voltage drops.
Safety information
This amplifier module is not intended for use in household electrical installations. It is intended exclusively for building prototypes and for testing and development purposes. Work on or directly next to the power supply must be carried out by a qualified electrician; if you are unsure, consult a qualified electrician before commissioning the device. Incorrect polarity or overloading may cause a fire hazard.
Scope of delivery
- 1x TDA7379 stereo amplifier module, AD828 preamp, 2x 38W
