Funduino Cube adapter board for ESP32 - solderless plug contacts

Product Overview

• Adapter board for ESP32 microcontrollers, providing relevant connections as plug contacts
• Simplified access to GPIO pins, power supply, and communication interfaces
• Compatible with breadboards and DIN rail installations with standard grid spacing
• Enables rapid prototype setups without soldering
• Components mounted on both sides for a compact board design

Product Description

An adapter board for ESP32 microcontrollers brings the chip's connections into a manageable form. It accommodates the module and routes the most important signal lines to plug contacts, allowing setups and rewiring without soldering.

The ESP32 itself remains mounted on the board; the adapter board rearranges its pins and therefore requires no external power supply apart from that of the ESP32 module itself. The design uses components mounted on both sides to keep the dimensions compact.

A typical application is the rapid setup of test configurations with sensors, actuators, and other components on a breadboard or experimenter's panel. It can also be used as a control element in larger systems if the ESP32's computing power and networking capabilities are sufficient.

The product is intended exclusively for prototyping and development. There is no specific pin pattern between the board and groups of components; the openings and grid dimensions of the processed connector system apply.

Safety Notice

The adapter board is intended exclusively for prototyping and for testing and development purposes. Work on or near electrical installations is reserved for qualified electricians. When operating with a power source, observe the maximum current consumption of all connected components to prevent overloading the ESP32's power supply.

Scope of Delivery

• 1* Funduino Cube Adapter Board - ESP32
