OMTech M-60 Laser Engraver - 60 W MOPA fiber laser, 175 x 175 mm

The OMTech M-60 is a 60 W JPT MOPA laser engraving machine for color metal engraving and precise metal marking. Its Galvo-Tech drive and scanning system achieves processing speeds of up to 7,000 mm/s with a work area of 175 x 175 mm.

With a 1-4,000 kHz frequency range and adjustable pulse width of 2-500 ns, the M-60 offers flexible options for different marking tasks. These include words, logos, images, barcodes, personalized jewelry, and high-contrast marking on aluminum and other metals.

Highlights

• 60 W JPT MOPA laser: for powerful and flexible metal marking
• 2-500 ns pulse width: wide adjustment range for different engraving applications
• 1-4,000 kHz frequency range: versatile parameterization
• Up to 7,000 mm/s: fast Galvo-based processing
• ±0.1 μm laser precision: for fine lettering, logos, images, and barcodes
• 175 x 175 mm work area: compact workspace for a wide range of projects
• Red frame preview: supports alignment and positioning before engraving
• Rotary engraving expandable: via a 4-pin connection with an optional rotary axis attachment

Product images

Materials and applications

• Color metal engraving and metal marking
• Words, logos, images, and barcodes on metal
• High-contrast marking on aluminum and other metals
• Personalized gold and silver jewelry
• Rings, bracelets, and other curved surfaces with rotary axis attachment

Safety features

• Protective enclosure: The laser stops automatically when the door is opened.
• Emergency stop button: enables immediate shutdown of operation.
• Fiber laser limit switch: supports precise and consistent positioning.

Technical data

Software and compatibility

EzCad2 is pre-installed. LightBurn, AutoCAD, and CorelDraw are also listed as compatible software. LightBurn is available for Windows, MacOS, and Linux.

Scope of delivery

• 1 x MOPA laser engraving machine
• 1 x Monitor mount
• 1 x Safety glasses
• 8 x Allen keys
• 1 x Power cable
• 1 x Foot switch
• 1 x USB stick
• 1 x Grounding cable
• 1 x Accessory box
• 2 x Mounting clamps
• 4-6 x Mounting screws
• 1 x Tape measure
• 1 x User manual

Warranty

• Fiber laser source: one-year warranty
• In the event of quality problems during the first year, free replacement of the fiber laser source is stated.
• Repairs are possible in the second year.

Notes

• The rotary axis attachment is not included in the standard scope of delivery.
• The free LRA-602D rotary axis and 12 stainless steel cups mentioned on the product page are part of the currently displayed promotional selection.
• The suitability of the respective material and appropriate laser parameters must be checked before processing.
