DK-C-01 Time Relay - Programmable, 12 V, DIN Rail
This goes with it
Pay in 30 days
Pay in 30 days
Description
Product overview
- Programmable timer control for 12 V DC systems
- Multiple switching functions, switch-on/switch-off delay, pulse generator, cycle and repeat modes
- DIN rail or wall mounting according to DIN
- Built-in mechanical and electronic indicators
- Programming via the front panel without external devices
- Control current and load contacts designed separately
Product description
This programmable timer relay automatically controls 12 V circuits according to predefined timing patterns. The module combines multiple switching functions in one device: it delays switching on and off, generates pulses when required, or switches loads on and off cyclically. Programming is performed directly on the front panel without external electronics, eliminating cumbersome trial and error when making adjustments during operation.
Because the control inputs and switching contacts are designed separately, the relay can be integrated flexibly into existing 12 V circuits. It can be mounted on DIN rails or screwed to a wall. The mechanical and electronic indicators show the switching status immediately, allowing faults to be detected quickly.
The timer relay is suitable for automation tasks in which devices need to be activated at specific times, maintenance pumps for irrigation systems, ventilation fans that run for a few seconds before operation resumes after breaks, or signal lines in control cabinets. It also operates reliably wherever repeated short switching sequences are required, such as cyclically switching a heater on and off.
The device requires a regulated 12 V power supply, which is usually already available in automation setups. The datasheet specifies the maximum permissible load current. Installation requires no special tools.
Safety information
This relay is not intended for installation in household mains circuits. It is intended exclusively for building prototypes and for testing and development purposes. Work on or near electrical installations must be performed by qualified electricians; if you have questions about safe wiring, consult a qualified electrician before commissioning.
Scope of delivery
1x Multifunctional timer relay - Programmable - 12V - DK-C-01
